GPON OLT optical module factory direct sales

25G SFP28 PON OLT 1358nm/1270nm SC 20km Transceiver

SKU: A5T-NSS2-20DC Product Highlights Support ITU_T G.988.5 25 GPON OLT application Single fiber Bi-directional data links, and the 25G PON upstream signals are in Wavelength Division Multiplex mode 25G PON 1358nm 24.8832G continuous-mode transmitter with EML laser, 1286nm 24.8832G burst-mode receiver with APD_TIA (with reset)&1270nm9.95328G burst-mode receiver with APD_TIA (with reset) 2-wire interface for integrated digital diagnostic monitoring Digital receiving signal strength indication(RSSI) SFP28 MSA package with SC/UPC receptacle optical interface +3.3V power supply

Hot Tags : 25G PON OLT SFP28 25G SFP28 PON OLT 20km 25G PON OLT SFP28 transceiver SFP28 25G PON 20km PON OLT SFP28 A5T-NSS2-20DC
Read More >>
2.5G/1.25G GPON OLT SFP Class B+ Tx1490nm/Rx1310nm 20km Transceiver

SKU: GPT-NSS2-20DC Product Highlights Single fiber bi-directional data links with 2.5Gbps upstream and 1.25Gbps downstream Integrated with micro-optics WDM filter at 1490/1310nm 1490nm Continuous Mode 2.488 Gbps DFB Transmitter 1310nm Burst Mode 1.244 Gbps APD-TIA Receiver LVTTL receiver Fast Burst Packet Detect indication Burst mode received signal strength indication (RSSI) function Single 3.3V power supply, 20km reach

Hot Tags : GPON OLT SFP Module GPON OLT SFP 20km 2.5G/1.25G GPON OLT SFP FIBERTOP GPON OLT SFP 20km GPON OLT SFP Class B+ GPT-NSS2-20DC
Read More >>
2.5G/1.25G GPON OLT SFP Class C+ Tx1490nm/Rx1310nm 20km Transceiver

SKU: GPT-NSS3-20DC Product Highlights Single fiber bi-directional data links with 2.5Gbps upstream and 1.25Gbps downstream Integrated with micro-optics WDM filter at 1490/1310nm 1490nm Continuous Mode 2.488 Gbps DFB Transmitter 1310nm Burst Mode 1.244 Gbps APD-TIA Receiver LVTTL receiver Fast Burst Packet Detect indication Burst mode received signal strength indication (RSSI) function Single 3.3V power supply, 20km reach Complies with Telcordia (Bellcore) GR-468-CORE,Complies with ITU-T G.984.2 Class C+ Class I laser safety standard IEC-60825 compliant,Compliant with SFP MSA and SFF-8472

Hot Tags : GPON OLT class C+ GPON OLT SFP Class C+ 2.5G/1.25G GPON OLT SFP Transceiver GPON OLT SFP Transceiver GPON OLT SFP 20km GPT-NSS3-20DC
Read More >>
2.5G/1.25G GPON OLT SFP 20km SC/UPC Transceiver

SKU: GPT-NSS4-20DC Product Highlights SFP with SC/PC Connector Transceiver Up to 10.3Gb/s data links, Duplex LC connector 1490 nm DFB Tx with isolator 1310 nm APD Rx Digital diagnostics SFF-8472 Compliant 2488 Mbps continuous mode Transmission 1244 Mbps Burst mode receiver Data Rate

Hot Tags : 2.5G/1.25G GPON OLT SFP GPON OLT C++ SFP 2.5G GPON OLT SFP Transceiver 2.5G/1.25G SFP 1490nm-Tx/1310nm-Rx 20km 2.5G/1.25G GPON OLT SFP 20km GPT-NSS4-20DC
Read More >>
